FMI 36" - Replaceable Parts List; Parts Compatibility by Model

www.fmiproducts.com
124384-01a 19
KEY
NO. PART NO. DESCRIPTION QTY.
1 ** Face Assembly • • • • • • 1
2 ** Firebox Bottom Assembly • • • • • • 1
3 ** Firebox Bottom • • • • • • 1
4 ** Firebox Surround • • • • • • 1
5 ** Insulation Pan Support • • • • • • 1
6 ** Insulation Pan • • • • • • 1
7 ** Top Insulation • • • • • • 1
8 110454-03 Fireplace Top 36" • • 1
110454-02 Fireplace Top 42" • • 1
110454-01 Fireplace Top 50" • • 1
9 23490SA Standoff • • • • • • 4
10 ** Fireplace Surround Assembly • • • • • • 1
11 109720-02 Clearance Spacer • • • • • • 6
12 117891-01 Fireplace Handle Bracket • • • • • • 4
13 20042 Outside Air Cover Plate • • • • • • 2
14 21171 Gas Conduit Cover • • • • • • 4
15 109752-01 Conduit One • • • • • • 2
16 109752-02 Conduit Two • • • • • • 2
17 ** Heat Shield Support • • • • • • 1
18 123298-03 Ash Box Assembly • • • • • • 1
19 ** Firebox Top • • • • • • 1
20 109457-03 Screen 36" • 2
109457-02 Screen 42" • 2
109457-01 Screen 50" • 2
117556-03 Screen 36" Stainless • 2
117556-02 Screen 42" Stainless • 2
117556-01 Screen 50" Stainless • 2
21 20806 Screen Rod 36" • 2
110146-03 Screen Rod 42" • 2
110146-02 Screen Rod 50" • 2
117568-03 Screen Rod 36" Stainless • 2
117568-02 Screen Rod 42" Stainless • 2
117568-01 Screen Rod 50" Stainless • 2
22 109511-01 Hood 50" • 1
109511-02 Hood 42" • 1
109511-03 Hood 36" • 1
109511-04 Hood Stainless 36" • 1
109511-05 Hood Stainless 42" • 1
109511-06 Hood Stainless 50" • 1
PARTS AVAILABLE NOT SHOWN
109714-02 Side Firebrick Wall Spacers • • 4
114913-01 Rear Firebrick Wall Spacers • • 2
114913-01 Rear Firebrick Wall Spacers • • • • 6
** Not a eld replaceable part.
(V)U36 (V)U42 (V)U50
(V)Q36 (V)Q42 (V)Q50
PARTS
This list contains replaceable parts used in your rebox. When ordering parts, follow the
instructions listed under Replacement Parts on page 17 of this manual.
