2
For more information, visit www.desatech.com
GLOSSARY:
a) Flush Installations – a type of installation where the front
face of the fireplace is even or leveled with the wall.
b) Chase Installation – a type of installation where the
chimney is enclosed.
c) Perpendicular Side Wall – applies to the minimum
clearance between the sidewall and fireplace opening.
d) Combustible Material – a type of material that is
flammable.
e) Nailing Flange – the extended part on both sides of the
fireplace face that secures the fireplace.
f) Termination – a cap that is placed at the end of the
chimney pipe.
g) Outside Air Kit – a combustion air inlet that allows
combustion air to enter the firebox area through a duct.
h) K-Factor – the thermal conductivity value that is given to
a particular material.
INTRODUCTION:
This fireplace model is a wood burning fireplace intended and
approved for installation in either residential homes or
buildings of standard construction. This fireplace system
requires the utilization of DESA 8 inch, double-wall, and
snap-lock flue pipe system. Optional glass doors in several
finishes are available for this fireplace (See Replacement and
Accessories parts on page 11).
BEFORE YOU BEGIN:
Before beginning the installation of your fireplace, read these
instructions:
• All DESA components and fireplaces are safe when
installed according to this manual. Use of any
components that have not been designed and tested for
this fireplace system may cause a fire hazard.
• The DESA warranty will be voided by and DESA
disclaims any responsibility for the following actions:
a) Modification of the fireplace, components, doors,
chimney system, fans, air inlet system, damper
control, etc.
b) Use of any component part not manufactured or
approved by DESA in combination with a DESA
fireplace system.
PROPER INSTALLATION is the most important step in
ensuring safe and continuous operation of this fireplace.
SELECTING LOCATION:
To determine the safest and most efficient location for your
fireplace, consider the following guidelines:
• The location must allow for all proper clearances (see
page 3).
• The location should be in a place where the fireplace will
not be affected by drafts such as air condition ducts,
windows or doors.
• A location that avoids the cutting of joists or roof rafters
makes installation easier.
• If an outside air kit is to be installed, accessibility to
outside combustion air must be considered. In some
cases, this can be achieved through a vented crawl space.
For more details, see section on outside air kit installation
on page 4.
• If a gas line is to be installed, consider the location of gas
supply.
WARNING: SAFETY INFORMATION
• Do not store or use gasoline or any other flammable
vapors or liquids in the vicinity of this or any other
appliance.
• Due to high temperatures, the appliance should be
located out of traffic and away from furniture and
draperies.
• Do not place clothing or other flammable materials on
or near the appliance.
•
EVER leave children unattended when a fire is
burning in the fireplace.
• Improper installation, adjustment, alteration, services
or maintenance can cause injury, property damage, or
loss of life. Refer to this manual for assistance or
additional information. Consult a qualified installer or
local distributor.
• Check local and applicable codes before installing this
fireplace.
• This wood burning fireplace complies with the UL
127 standard as a FACTORY BUILT FIREPLACE
and is listed and tested by Underwriters
Laboratories Inc.
• Do not install a fireplace insert in this firebox unless
the manufacturer’s instructions with the insert
specifically state this firebox has been tested for use
with the insert.
• This fireplace is not intended to be used as a substitute
for a furnace to heat an entire home. Use for
supplementary heating only.
• This model is not for use in manufactured housing
(mobile homes).
