A.
B.
C.
D.
F.
E.
G.
A: Main wing
B: Main fuselage
C: Horizontal stabilizer (Left and Right)
D: Horizontal stabilizer tube
E: Spinner set
F: Screws (4-PA2.6*10MM,5-HKM3.0*25MM)
G: Propeller
Before assembly, please inspect the contents of the kit. The photo below details the contents of the kit and
labels. If any parts are missing or defective, please indentify the name or part number (refer to the spare
parts list near the end of the manual) then contact your local shop or email us: support@fmsmodel.com
Contents of Kit
4
Wingspan: 1100mm (43.3in)
Overall Length: 1235mm (48.6in)
Flying Weight: Around 1680g (59.3oz)
Motor Size: Brushless 3541-KV750
Wing Load: 71.8 g/dm² (0.16oz/in²)
Wing Area: 23.4 dm² (362.7 sq.in)
ESC: 40A
Servo: 9g Servo x 7
