A.
B.
C. D.
F. G.
E.
H.
I. J.
A: Fuselage
B: Main wing (Left and Right)
C: Vertical Stabilizer (Left and Right)
D: Horizontal Stabilizer (Left and Right)
E: Missile Set
F: Nose Cone
G: Canopy
H: Fiber Pipe
I: Linkage and Screws
(4-HKM3.0*10, 4-KA2.0*8)
J: Landing Gear Set
Before assembly, please inspect the contents of the kit. The photo below details the contents of the kit and
labels. If any parts are missing or defective, please indentify the name or part number (refer to the spare
parts list near the end of the manual) then contact your local shop or email us: support@fmsmodel.com
Contents of Kit
4
Wingspan: 715mm (28.1in)
Overall Length: 980mm (38.6in)
Flying Weight: Around 1025g (36.2 oz)
Motor Size: Brushless 2840-KV3150
Wing Load: 66.5g/dm² (0.15oz/in²)
Wing Area: 15.4dm² (238.7sq.in)
ESC: 40A
Servo: 9g Servo x 5
To Next Page
