This receiver ESC function supports the settings of battery type, drag brake and running mode .
After the motor is connected, each time the receiver is turned on, the motor first prompts the connected battery type,
and then prompts the throttle neutral position calibration information, namely automatically identifies the throttle neutral
position.
When the connected battery type is LiPo, such as 2S LiPo, the motor will fast beep twice (3 beeps represent 3S LiPo);
when the connected battery type is NiMH, the motor will fast beep once.
When the throttle neutral position is recognized, the motor will long beep once.
If the throttle neutral position is not recognized, the motor will continue to beep quickly. There is no power output from
the motor at this time.
Notes:
1. The ESC function is available for running until the self-inspection is completed (it takes about 3 seconds).
Otherwise, it may not be able to operate normally.
2. If you find that the motor steering is not correct during operation, you can set the throttle channel in reverse at the
transmitter side.
3. Normally, you must power on the transmitter and then receiver, and power off the receiver and then transmitter.
本接收机电调功能支持在发射机端设置电池类型设置、拖刹力度设置和运行模式（正转 / 反转、正转 / 反转 / 刹车 ) 的设置。
马达连接后，接收机每次开机后，马达先提示连接的电池类型，再提示油门中位校准信息。即自动识别油门中位位置。
当连接的电池类型为锂电时，如使用 2S 锂电，则马达响两声（3 声代表 3S 锂电）提示；如使用镍氢电池，则马达响一声提示；
当油门中位识别通过后，马达长响一声提示。
若未识别油门中位，马达持续发出“滴滴滴”的报警声提示，此时马达无动力输出。
注：
1. 电调功能必须等到开机自检完成后方可运行（大约 3 秒），否则可能无法正常动作 ;
2. 若运行时发现电机转向不对，则可在发射机端将油门通道反向设置即可 ;
3. 为了一切正常，请养成先开发射机再接收机通电以及先接收机断电再关闭发射机的习惯。
Receiver Introduction
接收机介绍
24
ESC Function Instruction
电调功能说明
Trouble Shooting
故障解决
Troubles
故障现象
The motor cannot start
and the LED is not on
after power-on.
The motor cannot start
and the motor will
continue to beep quickly
after power-on.
1. No power was supplied to the ESC. Check whether all ESC & battery joints or connections
have been well soldered or firmly connected.
2. The switch of receiver or the ESC
itself is damaged.
Return to factory for inspection and treatment.
上电后,指示灯不亮，电机
无法启动。
上电后,马达持续发出滴滴滴
的报警声，电机无法启动。
The RC car is going in
the reversed direction.
发射机做前进操作，车子
反而倒退。
The neutral of throttle channel of
transmitter is shift or changed.
发射机油门通道的中点偏移或改变。
Adjust the throttle channel of the transmitter to match
the existing neutral point.
调节发射机油门通道微调使之匹配电调现有中立点。
1.电调没有得到工作电压。
检查电池与电调有无连接问题以及相关插头是否有虚焊情况。
2.接收机开关或电调损坏。 返厂检测处理。
Possible Causes
可能原因
Solutions
解决方法
1. It may cause by the connection
sequence between output line of ESC
and motor line.
Exchange the position of two lines of motor.
2. The throttle direction of transmitter
is wrongly set.
Set throttle direction of transmitter to the opposite
direction.
1. 电调输出线和电机线的连接线序错误。 将电机的两条线互换位置即可。
2. 发射机油门方向设置错误。 将发射机油门通道的方向设置为相反方向。
