1. If it is not in use for a long time, unplug and take off the battery to prevent battery leakage.
2. The battery needs to be disconnected and take off from vehicle before it can be charged
3. Do not open, disassemble, or attempt to repair the battery.
Open the engine hood as shown, load the battery
into the battery compartment and secure it in
place with the silicone strap. Connect the battery
plug to the female connector of the receiver/ESC
combo unit, and then close the engine hood.
The battery plug :51005 2P Male
Battery compartment size：43 x 19.8 x 12mm
NOTE
26
Vehicle Setup
车辆设置
Connecting the battery
连接电池
1. 如果长时间不使用本产品，请断开电池连接，并将电池取出，以防漏液。
2. 给电池充电之前，请务必保证电池已断开连接，并已从车辆上取下。
3. 不要打开、拆解或试图维修电池。
如图所示，打开引擎盖，将电池放入电池舱并使用绑
带固定；将电池插头连接到接收机/电调一体装置的
母头，然后关闭引擎盖。
电池插头:
51005 2P Male
电池仓尺寸：43 x 19.8 x 12mm
注意
1
3
2
