The ST. D/R switch is used to adjust the servo travel amount CH1(Steering Trim), and can also adjust
the travel amount for CH3 as multiplexing mode.
The TH.D/R switch is used to adjust the servo travel amount for CH2(Throttle), and can also adjust the
travel amount for CH4 as multiplexing mode.
Refer to [Mode Switching] for multiplexing switching mode.
Adjustment range: 0-120%;
ST.D/R: Counterclockwise adjustment to increase the servo travel amount. The maximum value is 120%.
ST.D/R: Clockwise adjustment to decrease the servo amount. The minimum value is 0%.
TH.D/R: Counterclockwise adjustment to increase the servo amount. The maximum value is 120%.
TH.D/R: Clockwise adjustment to decrease the servo amount. The minimum value is 0%.
This function is for reusing the ST.TRIM and ST.D / R buttons for different channels
setting:
Under normal power-on condition, press the BIND button twice (within 1S) to switch between mode 1
and mode 2. By default, mode 1 is used.
Mode 1: R.LED is always on. G.LED is off. ST.TRIM is for CH1 trim. ST.D/R is for CH1 servo adjustment
. TH.TRIM is for CH2 throttle trim. TH.D/R is for CH2 throttle ser vo adjustment .
Mode 2: R.LED and G.LED are flashing alternately. ST.TRIM is for CH3 trim. ST.D/R is for CH3 servo
adjustment . TH.TRIM is for CH4 trim. TH.D/R is for CH4 servo adjustment .
16
D/R
舵量调节
Mode switching
模式切换
System Functions
系统功能
ST.D/R 为 CH1 方向舵量调节，可复用为 CH3 舵量调节；
TH.D/R为 CH2 油门舵量调节，可复用为 CH4 舵量调节；
调节范围：0 ~ 120%；
ST.D/R：逆时针调节，增加舵量，最大为 120%；
ST.D/R：顺时针调节，减小舵量最小为 0%。
TH.D/R：逆时针调节，增加舵量，最大为 120%；
TH.D/R：顺时针调节，减小舵量最小为 0%。
此功能用于将 ST.TRIM 及 ST.D/R 旋钮复用于 CH3、CH4 通道（详见 [微调 ]、[舵量调节 ]。
功能设置：
正常开机状态下快速短按两下对码按键（BIND）（1 秒 内）即可循环切换模式一、二，开机默认为模式一。
模式一：R.LED 指示灯常亮，G.LED 示灯不亮，ST.TRIM 调节 CH1 微调，ST.D/R 调节 CH1 舵量；
TH.TRIM 调节 CH2 油门微调，TH.D/R 调节 CH2 油门舵量；
模式二：R.LED 指示灯和 G.LED 指示灯交替闪烁，ST.TRIM 调节 CH3 微调，ST.D/R 调节 CH3 舵量；
TH.TRIM 调节 CH4 微调，TH.D/R 调节 CH4 舵量。
