HKM 3.0*40
Horizontal stabilizer installation
Vertical stabilizer installation
Main wing installation
4
Model assembly
1.Connect the rudder servo connectors to the servo extensions in
the fuselage. Install the vertical stabilizer in the rear of the
fuselage using foam-safe glue.
1.Remove the canopy hatch.
2.Guide the servo leads from main wing through the hole located
in the bottom of the fuselage.
3.Align the wing with the fuselage and secure into position using
screws included as shown.
EN
1.Connect the elevator servo connectors to the servo extensions
in the fuselage. Install the horizontal stabilizer to its housing in
the fuselage using foam-safe glue. Ensure the control horn faces
down as shown.
foam glue
foam glue
To Next Page
