7.0 REVERSING THE DOORS - CONTINUED
GB IE
3. Remove the door limit block from the bottom for the door with a screwdriver and refit on the opposite side.
Limit block
4. Remove the bottom door hinge pin fixing bracket with a screwdriver or a spanner. After the fixing bracket is removed it
will need to be fitted on the opposite side of the appliance. The bottom hinge pin fixing bracket is located underneath the
appliance and you need to tilt the appliance backwards to remove the bracket.
5. Remove the bottom door bush bearing and the limit block and refit on the opposite side.
6. Remove the screw hole covers.
IMPORTANT: The screw cap and screw hole covers should be retained for use on the opposite side of the appliance.
