INTEGRATION FLAT AMPLIFIED BASS ENCLOSURE
User manual
5
APower supply wire +12 Volts (yellow)FSpeaker connector
BGround cable (Black)GHigh level connector
CRemote cable (Blue)HPower supply connector and car speakers
DPower supply connectorICar radio connectors
EPower supply connector and speakersJRemote control wire
KRemote control
If your car radio is without ISO connector, you must get an ISO adapter.
Installation
Photo legend page 12
