Focal IC RNS 165 - Specifications

Woofer
Nominal power 60W
Maximum power 120W
Sensitivity
(2,83V/1m)
92 dB
Cone Braided glass fiber
®
Surround Butyl
Nom. impedance 4
DC resistance 3.5
VC diameter 25mm
1"
VC height 11mm 0
5/16
"
Former Kapton
Layers 2
Wire Copper
Inductance
Xmax 2.5mm 0
1/16
"
Magnet d x h 85mm x 15mm 3
1/3
x0
9/16
"
Magnet weight 0.35kg
0.66lb
Flux density 1.3T
Gap height 5.5mm 0
3/16
"
Net weight 850g
1.87lb
Fs 79.28Hz
Vas 7.44I
Qts 0.92
Qes 1.04
Qms 7.94
Re 3.54 Ohms
Sd 1373cm

Cas 6.04 E-08m

N
Mas 66.75kgm

Ras 4187.53 Ohmsac
Cms 3.22E-04 m/N
Mms 12.5g
Rms 0.784kgs
Ces 596.52mF
Les 6.76mH
Res 26.72 Ohms
BI 4.58NA
SPL 87.93dB/W/m
SPECIFICATIONS
165
85
141
66
26
6
155


Log Frequency - Hz












dB SPL











Ohms
Focal
®
is a trademark of Focal-JMLab
®
- www.focal.com - SCAA190319/1
IC RNS 165
Technical Sheet
FREQUENCY RESPONSE/IMPEDANCE
MECHANICAL DRAWING
PARAMETERS
