Focal Sib Evo - Specs

7
SIB EVO - SIB EVO DOLBY ATMOS®
Manuel d’utilisation / User Manual
Sib Evo
Type Two-way compact bass-reflex loudspeaker
Speaker 5" (13cm) Polyflex woofer
3/4" (19mm) soft dome tweeter
Frequency Response (+/-3dB) 70Hz to 25kHz
Low frequency point -6dB 66Hz
Sensibility (2.83V/1m) 90dB
Nominal Impedance 6 Ohms
Crossover Frequency 3.5kHz
Recommended Amplifier Power 25 - 200W
Dimensions (HxWxD) 9
15/16
Ǝx6
3/8
Ǝx6
3/8
Ǝ (252x162x162mm)
Weight (unit) 4lbs (1.8kg)
Specifications
Sib Evo Dolby Atmos®
Front Channel Atmos® Channel
Type Two-way
bass-reflex loudspeaker
Fullrange sealed
loudspeaker
Speakers 5" (13cm) Polyflex woofer
3/4" (19mm) soft dome
tweeter
4Ǝ (10cm) full-range speaker
Frequency Response (+/-3dB) 65Hz to 25KHz 90Hz to 20KHz
Low frequency point -6dB 60Hz 75Hz
Sensibility (2.83V/1m) 90dB 90dB
Nominal impedance 6 Ohms 6 Ohms
Crossover Frequency 3.5kHz
Recommended Amplifier Power 25 - 200W
Dimensions (HxWxD) 11
5/8
Ǝx7
11/16
Ǝx7
1/2
Ǝ
(295x195x190mm)
Weight (unit) 7lbs (3.25 kg)
