18
HARDWARE FEATURES
Front/Side Panels
6
4
5
1 1
2 3
The front panel includes the input connectors for mic and line/instrument signals, and the input gain
control.
1. iPhone slot
2. Right microphone position (behind grille)
3. Left microphone position (behind grille)
4. Recording level control (at side)
5. Instrument input – ¼” jack socket (at side)
6. Clip LED – illuminates when recording level is too high
Rear Panel
7
7. DEVICE LINK port – connect to iPhone using supplied cable
