1.1 Motherboard SPEC
Size
- Mini 154.8mm*117.4mm
CPU
- Intel BayTrail J1900 2.42GHz 2M quad core
Chipset
- Intel BayTrail J1900
RAM
- DDR3 SO-DIMM Max Support 4GB
Display Chip
- Intel® HD Graphics
Onboard Lan Function
-Realtek RTL8111E Gigabit.Support wake-up function.
Rear I/O port
-2 * RJ-45 Lan interface and LED indicator light.
-2 * USB2.0 port
-1 * VGA Port
-1 *HDMI Port
-1 * Video Input
-1 * Video Output
-1 * DC Input Port
Connector
-1 * Memory slot
-1 * SATA connector
-1 * MINI PCIE Port
-1 * MINI SATA port（Back end ）
-1 * SIM slot
-1 * INVERT Port
-CPU/SYS fans port
-CMOS Remove Pin
-6 * 9PIN RS-232 Pin（COM1/2/3/4/5/6）
-1 * 4PIN RS485/422 Pin(Optional)
-1 * GPIO Pin
-1 * LVDS Pin
-1 * EDP Pin
-1 * IDE_ PWR Pin
-3 * USB 2.0 Pin
-Video F_AUDIO Pin
-System Panel F_PANEL Pin
BIOS
-32MB AMI BIOS
-Plug and play support
-ACPI 1.1 power management
-support wake-up function
Operating temperature
- -40℃~ 60℃
Storage Temperature
- -25℃ ~ 70℃
Operating Humidity
-5% ~ 95%（No Condensation）
OS Support
-Windows XP、Win7、Win8、Linux
