TECHNICAL SPECIFICATIONS
MA-125 MA-245
CHARACTERISTICS PA amplifier.
Phantom power supply.
Priority paging.
POWER 180 W maximum, 120 W RMS 360 W maximum, 240 W RMS
RESPONSE 80-16 000 Hz ±3 dB
DISTORTION Harmonic: < 1 % at 1 kHz
INPUTS 4 balanced mics./lines, combo (XLR and 6.3 mm jack) 600 Ω 2 mV and
47,000 Ω 150 mV, switchable
1 aux, 2 x RCA, 47,000 Ω 300 mV
1 amp in, RCA 10,000 Ω 1 V
1 tel. input, screw terminal blocks 600 Ω 100 mV
OUTPUTS 1 line out, 2 x RCA 47,000 Ω 1 V
1 pre out, RCA 600 Ω 1 V
1 monitor, screw terminal blocks 600 Ω 775 mV and 1 W 8 Ω (aux input)
CONTROLS Tone:
Bass: ±10 dB
Treble: ±10 dB
Volume: inputs 1 to 4, aux and general volume
PHANTOM 24 V in mics 1 to 4, selectable
PRIORITY Tel. input and mic. 1 depending on signal level, selectable
IMPEDANCE 4 Ω and 100, 70 and 25 V lines, screw terminals
POWER SUPPLY 230/115 V AC, 290 W and 24 V
DC, 161 W
230/115 V AC, 600 W and 24 DC,
312 W
DIMENSIONS 420 x 89 x 300 mm depth. 2 U 19” rack
OPTIONAL MA-2N: mounts for assembly in 19” rack
- 7-
EN
