TECHNICAL SPECIFICATIONS
PROX-60Z
FEATURES PA Amplifier.
BLUETOOTH
®
/USB/FM player.
Microphone inputs with mix, gain and priority level control.
Tone controls.
100 V and 4 Ω outputs.
Output zones with volume control and Off.
POWER 60 W RMS
RESPONSE 60-20,000 Hz -10 dB
DISTORTION THD+N: < 1% to 1 kHz
S/N RATIO >77 dB
PROTECTIONS Overcurrent, DC and short-circuit at the output
INPUTS CH 1: 1 balanced mic/line with 48 V Phantom, Combo (XLR + 6.3 mm) and euroblock.
Mic: 600 Ω, 6 mV RMS (-44 dBV). Line: 100k Ω, 250 mV RMS (-12 dBV).
CH 2: 1 balanced mic/line with 48V Phantom, euroblock. Mic: 600 Ω, 6 mV RMS (-44 dBV).
Line: 100k Ω, 250 mV RMS (-12 dBV).
2 Aux, euroblock/2 x RCA, 47,000 Ω 300 mV RMS (-10 dBV)
1 x 100 V line emergency, euroblock.
Mute (Emergency Priority) by contact closure, euroblock
OUTPUTS 1 line, 2 x RCA, 1.25 V RMS (+2 dBu)
2 x 100 V speaker zones with 5-position volume selector switch and OFF
FUNCTIONS Input priority.
Emergency Input 100V with maximum priority, attenuates all other inputs.
Mute by contact closure, attenuates all inputs except the 100V Emergency input.
Channel 1 with priority over other inputs, level selectable.
Channel 2 with priority over Aux inputs, level selectable.
Power on, protection, signal peak and output signal indicator lights.
Fanless induction cooling
CONTROLS Microphone volume
Mic/line/phantom selector
Master volume
Aux input or player selector
Zone volume
Tone: bass and treble (+/- 10 dB 100 Hz and 10k Hz)
Microphone gain
Priority activation signal level (VOX)
PLAYER BLUETOOTH
®
/USB/FM player for background music playback
Autoplay, playback starts automatically when power is switched on
Memory of last selected mode
Play mode memory (random, repeat)
IMPEDANCE 4 Ω and 100 V line (166 Ω), euroblock
OPERATING
TEMPERATURE
0º ~ 40ºC
MAXIMUM
HUMIDITY
95%
POWER SUPPLY 230/115 V AC 50-60 Hz, 200 W
Fuse AC 230 V 1.5 A / 115 V 3.15A
DIMENSIONS 320 x 84 x 241 mm depth
ACCESSORIES FM antenna -
BLUETOOTH
®
antenna - Power cable
