Forbidden DRUID - Bike Assembly Guide; Getting Ready for Assembly; Connect Dropper Post Cable; Install Dropper Post

DRUID ASSEMBLY MANUAL \ ASSEMBLY
04
CAUTION: READ THIS MANUAL IN ITS ENTIRETY BEFORE ASSEMBLING YOUR NEW BIKE.
02. CONNECT DROPPER
POST CABLE
a. Fit cable end nut into
the cradle at the bottom
of the seatpost.
b. Pull the housing away
from the cable end nut and
align the housing into the
housing stop at the bottom
of the seatpost.
01. GETTING READY
a. Open the box top and
remove the small parts box,
set this aside.
b. Take your bike out of the
box and remove packaging,
being careful not to scratch
your new ride. Set the front
wheel safely aside.
c. Put the rear end of the
bike back in the box with the
fork overhanging outside of
the box. This will help make
the next few steps easier.
03. INSTALL DROPPER POST
c. While gently pulling on
the seatpost remote cable
housing, continue to insert
the seat post to your desired
height.
b. Apply a thin layer of
grease and insert the seat
post into the seat tube about
one inch.
e. Using a 4mm Allen key,
pull gently on remote cable
housing and re-tighten cable
port to 1-2Nm.
d. Tighten the seatpost
clamp to 6Nm.
b. Ensure cables are properly
routed and mount the
handlebar on the stem.
04. INSTALL HANDLEBAR
a. Using a 4mm Allen
key, remove all four
stem faceplate bolts.
d. Using a 4mm Allen key,
re-install faceplate and
faceplate bolts adhering
to the manufacture’s
specications.
RaceFace Aeect: tighten
the top two bolts so the
faceplate is flush with the
stem and then tighten the
bottom two bolts equally to
6Nm. Check all four bolts
once more to ensure 6Nm.
c. Double check the
orientation of the stem face-
plate by conrming which is
the top on the reverse side.
d. Remove the card
containing the bike’s
serial number and store
in a safe place.
a. Using a 4mm Allen key,
loosen the dropper post
cable port (drive side, near
the head tube) one full turn.
