ENTER
This function allows the user to find out the last time and date the
"Amount Used" display was cleared or reset for each scale.
NOTE: You must have purchased the low level alarm option and your alarm must be
enabled under Code Set-Up #4200 for this function to operate. (See Chapter "SET-UP CODES")
LOW LEVEL ALARM
SCALE 1 = X LB.
Displays DATE and TIME "AMOUNT USED" function was last
cleared is displayed for 8 seconds
Enter low level VALUE via key pad for SCALE 2...
then press (Example: Low level set point 150 lbs)
Enter low level VALUE via key pad for SCALE 1...
then press (Example: Low level set point 100 lbs)
ENTER
ENTER
LOW LEVEL ALARM
THEN PRESS ENTER
Allows you to enter your low level set point values for the optional low level alarm. For this function to work properly,
the alarm must be "enabled" under the Set-up Code #4200. Be sure to read this set-up code thoroughly before
using this function. When a low level condition exists, your display will continuously flash "Low Level Scale #_____"
and the optional 5 AMP relay will be activated. (See Chapter "SET-UP CODES")
LOW LEVEL ALARM
SCALE 2 = X LB.
DATE LAST CLEARED
THEN PRESS ENTER
ENTER SCALE #
1 THRU 2 X
SCALE 2 CLEARED
09/15/95 22:15
(or 1 thru 4)
Press to continue.
Press to continue.
Enter which scale NUMBER... then press
ENTER
ENTER
Digital Display
Action Required - Press "ENTER" after completing each step.
Action Required - Press "ENTER" after completing each step.
Digital Display
Step 1
Step 2
Step 3
Step 1
Step 2
Step 3
This menu contains a list of operations that are used on a frequent basis. Each menu item is followed by
"THEN PRESS ENTER" and has step-by-step operating instructions.
DATE LAST CLEARED
LOW LEVEL ALARM
MENU OF DAY-TO-DAY OPERATIONS
QUESTIONS ? Help Hotline: 1-800-893-6723
W.2.104
1150-D Burnett Ave, Concord, CA 94520 USA
1-800-893-6723 US & Canada, Fax: 925-686-6713
www.forceflow.com / info@forceflow.com
File: T4\O&M\AWZMSTR\WZDAY2.tcw (B08.pdf)
