PORT 1 RANGE FS
NET WT = ________
Enter FULL SCALE range for the scale on PORT 1
NOTE: If you choose "NET WEIGHT": We recommend that you set
your full scale range equal to your scale capacity.
If you choose "RATE": Set your full scale equal to the maximum
feed rate which you expect to see on that scale.
Use ARROW KEY to choose (for the scale on PORT 1), either:
RATE (Rate of Feed) or
NET WT (Net Weight)
___RATE ___NT WT
1150-D Burnett Ave, Concord, CA 94520 USA
1-800-893-6723 US & Canada, Fax: 925-686-6713
www.forceflow.com / info@forceflow.com
File: T4\O&M\AWZMSTR\WZSETUP5.tcw 11/99 (B18.pdf)
QUESTIONS ? Help Hotline: 1-800-893-6723
FORCE FLOW
FORCE FLOW
F
F
L
L
O
O
Q
Q
I
I
U
U
P
P
W.2.206
Action Required - Press "ENTER" after completing each step
Digital Display / Default (in red)
If you have chosen the analog output option, this allows you to select either net weight or feed rate as
your output. This option requires a special access code.
TRANSMIT SCALE
*SINGLE TOTAL
This allows you to choose between transmitting the TOTAL of ALL
SCALES, or transmitting INDIVIDUAL SCALES (when "total" is
chosen, transmitting is ALWAYS done on PORT 1). Use
ARROW KEY to select, then ENTER.
HOW MANY PORTS ?
1 thru 4 _______
How many scales will have transmitters?
Choices: "1", "2", "3" or "4"
PORT 1 SCALE
NUMBER = ______
Which scale will have PORT 1?
NOTE: We recommend using Port 1 for Scale 1,
Port 2 for Scale 2, etc.
ENTER CODE
NUMBER = ______
Enter the PASSWORD to continue. Required to access this option.
(Optional Accessory)
4-20 MA OUTPUT?
1 = Y 0 = N ______
To activate the 4-20 MA option.
Choices: "1" = YES "0" = NO
3256 4-20 MA ANALOG OUTPUT CONFIGURATION
