This option requires a special access code, which will be provided when this option is supplied.
For Scale ONE. Do you want your alarm latching?
#1 SET POINT LATCHED
1 = Y 0 = N ______
#1 SET POINT ENABLED
1 = Y 0 = N ______
For Scale ONE. Do you want to turn the low level alarm ON or OFF.
Choice: "1" = ON "0" = OFF
Digital Display / Default (in red)
Action Required - Press "ENTER" after completing each step
Enter the PASSWORD to continue. Required to access this option.
(Optional Accessory)
THIS UNIT CONTAINS:
4200 SET POINT CONFIGURATION
Choose: "1" =
Choose: "0" =
NOTE: Questions repeat for each additional scale.
LATCHING (alarm condition exists until
operator acknowledges the alarm by re-setting in the menu)
NON-LATCHING (alarm condition exists until tank is refilled)
ENTER CODE
NUMBER = ______
Dry Contact Relays
Solid State Relay
N/O (Normally Open)
N/C (Normally Closed)
1150-D Burnett Ave, Concord, CA 94520 USA
1-800-893-6723 US & Canada, Fax: 925-686-6713
www.forceflow.com / info@forceflow.com
File: T4\O&M\AWZMSTR\WZSTUP4A.tcw (3/05/02) (B17.pdf)
QUESTIONS ? Help Hotline: 1-800-893-6723
FORCE FLOW
FORCE FLOW
F
F
L
L
O
O
Q
Q
I
I
U
U
P
P
W.2.205
For ALL Scales: Do you want to invert the operation of the relays?
INVERT RELAYS ?
1 = Y 0 = N ______
Choose "1" =
The relay will be actuated in a NON-ALARM condition.
If an ALARM condition occurs, relay is de-activated.
EXAMPLE:
If "INVERTED RELAY" is selected, a Normally
Closed relay will be actuated (OPENED contact)
in NON-ALARM status. During an ALARM
situation, relay is de-actuated (CLOSED contact).
Choose "0" =
The relay will be actuated when an ALARM situation
is encountered.
EXAMPLE:
If "INVERTED RELAY" is NOT selected, a Normally
Closed relay will NOT be actuated (CLOSED contact)
in NON-ALARM status. During an ALARM
situation, relay is actuated (OPEN contact).
This feature allows configuration of FAIL SAFE alarm
relay contacts.
To Next Page
