Force Flow WIZARD 4000 - Troubleshooting; Menu and Code Access Issues; Incorrect Usage;Data Values; Alarm and Printer Issues

QUESTIONS ? Help Hotline: 1-800-893-6723
W.3.301
1150-D Burnett Ave, Concord, CA 94520 USA
1-800-893-6723 US & Canada, Fax: 925-686-6713
www.forceflow.com / info@forceflow.com
File: T4\O&M\AWZMSTR\WZTRBSHT.tcw (B20.pdf)
FORCE FLOW FORCE FLOW
F F L L O O Q Q I I U U P P
- Exit CODE SET-UP function, then push "arrow" key.
Cannot get INTO the MENU:
PROBLEM SOLUTION
Cannot get OUT OF the MENU:
Cannot get OUT OF the CODE SET-UP:
AMOUNT USED and DAILY
USAGE values are incorrect.:
NET REMAINING is NOTcorrect:
FEED RATE and DAYS UNTIL
EMPTY is incorrect:
ALARM does NOT operate:
Alarm RESET does NOT operate:
PRINTER does NOT operate:
4-20mA SIGNAL does NOT operate:
READOUT does NOT operate:
Fluctuating readings or
inacurate readings.
- Push DELETE
- Keep pushing ENTER until you get to the display.
- When in the TANK LOAD mode, make sure you wait until the:
"CHANGE TANKS NOW" (for PORTABLE tank applications)
or "FILL TANKS NOW" (for PERMANENT tank applications)
before loading/unloading of tanks/chemicals.
- If using AUTO TARE mode, make sure you are using full tank(s).
- If you are using MANUAL TARE mode, make sure you are entering
the correct tare weight(s) for your tank(s).
- If you don't replace all tanks on a multiple tank scale, you must
use MANUAL mode.
- If all else fails, recalibrate under CODE SET-UP 9081 under field calibration.
- Read CODE SET-UP 9082 under custom formatting thoroughly and adjust accordingly.
- Make sure you purchased this option.
- Make sure alarm for that scale is ENABLED under CODE SET-UP 4200.
- Make sure relay is wired NORMALLY OPEN under indicator wiring instructions.
- You must first correct your alarm condition before attempting to reset
(i.e. fill your tank, or load a full tank beforehand).
- Make sure printer protocol has been set properly (see #4 PRINTER COMMUNICATIONS
in Indicator Installation & Wiring)
- Printer must have at least 24 character width capability and a 2K buffer.
- Make sure you purchased this option.
- Make sure there is no more than 975 Ohms load on 4-20mA loop.
- Make sure 4-20mA signal is formatted properly under CODE SET-UP 3256.
- Check for proper power connections.
- Check fues in Indicator.
- Make sure load cell cable is not in proximity to any other power wiring.
TROUBLESHOOTING
