ASSEMBLY DRAWING
KEY NUMBER DESCRIPTION OF PART QUANTITY
8 Flat Washer φ10 1
50 Reduction Sleeve φ32*φ26*25 6
51 Rubber Shock Pad φ50*50*30 1
52 Powder Powder Sleeve φ32*φ29*φ20*18 2
53 Countersunk Hexagon Rivet Nut M10 1
54 Hexagon Socket Countersunk Head Screw M10*30 1
55 Sleeve 1
52
54
8
51
53
50
50
55
