Fuse/Relay
Location
Fuse Amp
Rating
Description
8 30A* PCM Relay
9 20A* Fuel Pump Relay and RAP Module
10 15A* Horn Relay
11 15A* Parklamps Relay and Main Light Switch
12 30A* Main Light Switch and Multifunction Switch
13 15A* Heated Oxygen Sensor, EGR Vacuum
Regulator, EVR Solenoid, Camshaft Position
Sensor (CMP), Canister Vent Solenoid
14 30A* Generator Voltage Regulator
15 - NOT USED
1 - Wiper Park Relay
2 - A/C Relay
3 - Wiper Hi/Lo Relay
4 - PCM Power Relay
5 - Fuel Pump Relay
6 - Starter Relay
7 - Horn Relay
8 - Washer Pump Relay
9 - Blower Motor Relay
10 - Foglamp Relay
11 - Not Used
12 - Not Used
13 - Park Lamp/Trailer Tow Relay
14 - Not Used
1 - RABS Resistor
1 - RABS Diode
2 - Electronic Engine Controls Diode
* Mini Fuses ** Maxi Fuses
Roadside emergencies
100
