Fuse/
Relay
Location
Fuse
Amp
Rating
Description
29 15A Radio
30 15A Park Lamp/Trailer Tow Relay
31 — Not Used
32 — Not Used
33 15A Headlamps, Daytime Running Lamps (DRL)
Module, Instrument Cluster
34 — Not Used
35 10A RABS Test Connector
36 — Not Used
Power distribution box
The power distribution box is
located in the engine compartment
near the battery. The power
distribution box contains
high-current fuses that protect your
vehicle’s main electrical systems
from overloads.
Always disconnect the battery before servicing high current
fuses.
Always replace the cover to the Power Distribution Box before
reconnecting the battery or refilling fluid reservoirs.
Roadside emergencies
98
