WINDSHIELD
WASHER
FLUID
Checking
and
adding
washer
fluid
Check
the
washer
fluid
whenever
you
stop
for
fuel.
The
reservoir
is
highlighted
with
a
symbol.
If
the
level
is
low
,
add
enough
fluid
to
fill
the
reservoir
.
In
very
cold
weather
,
do
not
fill
the
reservoir
all
the
way
.
Do
not
put
engine
coolant
in
the
container
for
the
windshield
washer
fluid.
W
A
S
H
E
R
F
L
U
I
D
O
N
L
Y
RADIATOR
COOLANT
ONLY
Maintenance
and
care
120
119
121
