Ford 2000 Ranger - Shifting from 2 WD (2 WD High) to 4 X4 HIGH (4 WD High); Shifting from 4 X4 HIGH (4 WD High) to 2 WD (2 WD High); Shifting from 2 WD (2 WD High) to 4 X4 LOW (4 WD Low)

Shifting from 2WD (2WD high) to 4X4 HIGH (4WD high)
Move the 4WD control to the 4X4
HIGH position.
• At temperatures below 0°C
(32°F), shifts from 2WD to 4X4
HIGH should not be performed
above 72 km/h (45 mph).
Do not shift into 4X4 HIGH with
the rear wheels slipping.
Shifting from 4X4 HIGH (4WD high) to 2WD (2WD high)
Move the 4WD control to 2WD
position at any forward speed.
• You do not need to operate the
vehicle in R (Reverse) to
disengage your front hubs.
Shifting from 2WD (2WD high) to 4X4 LOW (4WD low)
1. Bring the vehicle to a stop.
2. Depress the brake.
3. Place the gearshift in N (Neutral) (automatic transmission) or depress
the clutch (manual transmission).
4. Move the 4WD control to the 4X4
LOW position.
4X4
HIGH
2WD
4X4
LOW
4X4
HIGH
2WD
4X4
LOW
4X4
HIGH
2WD
4X4
LOW
Driving
120
