Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment
Fuse Panel Description
21 15A Flasher (Hazard)
22 20A Auxiliary Power Socket
23 — Not Used
24 7.5A Clutch Pedal Position (CPP) switch, Starter
Interrupt Relay, Anti-Theft
25 — Not Used
26 10A Battery Saver Relay, Electronic Shift Relay,
Interior Lamp Relay, Power Window Relay,
Electronic Shift Control Module, Dome/Map
Lamp, GEM, Instrument Cluster
27 — Not Used
28 7.5A Generic Electronic Module (GEM), Radio
29 15A Radio
30 10A RABS Test Connector
31 — Not Used
32 — Not Used
33 15A Headlamps, Daytime Running Lamps (DRL)
Module, Instrument Cluster
34 — Not Used
35 — Not Used
36 — Not Used
Roadside emergencies
143
