Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box Description
9 20A* Fuel Pump Relay and RAP Module
10 15A* Horn Relay
11 15A* Parklamps Relay and Main Light Switch
12 30A* Main Light Switch and Multifunction Switch
13 15A* Heated Oxygen Sensor, EGR Vacuum
Regulator, EVR Solenoid, Camshaft Position
Sensor (CMP), Canister Vent Solenoid
14 30A* Alternator Voltage Regulator
15 — Not Used
1 — Wiper Park Relay
2 — A/C Relay
3 — Wiper Hi/Lo Relay
4 — PCM Power Relay
5 — Fuel Pump Relay
6 — Starter Relay
7 — Horn Relay
8 — Fog Lamp Control Relay
9 — Blower Motor Relay
10 — Foglamp Isolation Relay
11 — Not Used
12 — Not Used
13 — Park Lamp/Trailer Tow Relay
14 — Washer Pump Relay
1 — RABS Resistor
1 — RABS Diode
2 — Electronic Engine Controls Diode
* Mini Fuses ** Maxi Fuses
Roadside emergencies
146
