Fluid Ford Part
Name
Application Capacity
Front axle
lubricant
Motorcraft SAE
80W-90
Premium Rear
Axle Lubricant
4x4 Vehicles 1.7L (3.6 pints)
Rear axle
lubricant
5
Motorcraft SAE
80W-90
Premium Rear
Axle Lubricant
All 2.4-2.5L
(5.0-5.3 pints)
Windshield
washer fluid
Ultra-Clear
Windshield
Washer
Concentrate
All 2.6L
(2.75 quarts)
1
Ensure the correct automatic transmission fluid is used. MERCONt and
MERCONt V are not interchangeable. DO NOT MIX MERCONt and
MERCONt V. Refer to the Scheduled Maintenance Guide to determine
the correct service interval.
2
Service refill capacity is determined by filling the transmission to the
bottom of the filler hole with the vehicle on a level surface.
3
Indicates only approximate dry-fill capacity. Some applications may
vary based on cooler size and if equipped with an in-tank cooler. The
amount of transmission fluid and fluid level should be set by the
indication on the dipstick’s normal operating range.
4
Use Ford Premium Engine Coolant (green in color). DO NOT USE Ford
Extended Life Engine Coolant (orange in color). Refer to Adding engine
coolant, in the Maintenance and Care chapter.
5
Traction-Lok axles use 2.2–2.4L (4.75–5.0 pints) of rear axle lubricant.
Add 118 ml (4 oz.) of Additive Friction Modifier C8AZ-19B546-A or
equivalent meeting Ford specification EST-M2C118–A for complete refill
of Traction-Lok axles.
Service refill capacities are determined by filling the rear axle 6 mm to
14 mm (1/4 inch to 9/16 inch) below the bottom of the filler hole.
Capacities and specifications
211
