Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
11 10A Smart Junction Box (SJB) (Logic
power)
12 15A Center console subwoofer
amplifier
13 15A Horn, Interior lamps
14 15A High beam headlamp, High beam
indicator (cluster)
15 — One-touch down relay
16 30A cartridge
fuse
Power windows
17 15A Turn signals/Hazards
18 — Not used
19 20A Center High-Mounted Stop Lamp
(CHMSL)/Stop lamps
20 10A Anti-lock Brake System (ABS)
module, Brake-shift interlock,
Speed control module, Back-up
lamps, Overdrive cancel switch,
Electronic flasher (turn/hazard)
21 5A Starter relay
22 5A Radio (START), 4x4 Neutral
sense (manual only)
23 30A Headlamps (low and high beam)
24 20A Radio
25 — Accessory relay
26 2A Brake pressure switch
27 10A Climate control blower relay/blend
doors, 4x4 module
28 15A 4x4 module B+
29 20A Cigar lighter or power point,
Diagnostic connector (OBD II)
30 5A Power mirrors
2005 Ranger (ran)
Owners Guide (post-2002-fmt)
USA (fus)
Roadside Emergencies
164
