T
ransmission/T
ransaxle
code
designations
Y
ou
can
find
a
transmission/transaxle
code
on
the
vehicle
certification
label.
The
following
table
tells
you
which
transmission
or
transaxle
each
code
represents.
Code
Description
D
Five-speed
automatic
(5R44E/5R55E)
J
Five-speed
manual
(HD)
M
Five-speed
manual
(R1)
2005
Ranger
(ran)
Owners
Guide
(post-2002-fmt)
USA
(fus)
Maintenance
and
Specifications
242
241
243
