FUSE BOX LOCA
TIONS
A
B
C
D
E70864
Pre-fuse box
A
Standard relay box
B
Passenger compartment
junction box
C
Engine compartment
junction box
D
Pre-fuse box
E70866
The pre-fuse box is located inside the
pedestal of the driver's seat.
Standard relay box
E70869
E70868
The standard relay box is located
behind the glove box.
T
o access the standard relay box:
•
Open the glove box.
•
Press the sides inwards and allow
the glove box to pivot
downwards.
108
Fuses
109
111
