Never remove the coolant reservoir cap while the engine is
running or hot.
Fuel gauge: Indicates
approximately how much fuel is left
in the fuel tank (when the ignition
is in the ON position). The fuel
gauge may vary slightly when the
vehicle is in motion or on a grade.
The FUEL icon and arrow indicates
which side of the vehicle the fuel
filler door is located.
Refer to Filling the tank in the Maintenance and Specifications
chapter for more information.
Tachometer: Indicates the engine
speed in revolutions per minute.
Driving with your tachometer
pointer continuously at the top of
the scale may damage the engine.
Odometer: Registers the total miles (kilometers) of the vehicle.
• Without Message Center
• With Message Center
Refer to Message Center in the
Driver Controls chapter on how to
switch the display from Metric to
English.
E
F
2007 Fusion (fsn)
Owners Guide (post-2002-fmt)
USA (fus)
Instrument Cluster
15
