Ford 2007 Fusion User Manual

Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
31 — Not used
32 30A** Driver power seat
33 20A** Moon roof
34 — Not used
35 — Not used
36 1A* PCM diode
37 — Not used
38 — Not used
39 — Not used
40 — Not used
41 Relay Fog lamp relay
42 Relay Wiper park relay
43 Relay A/C clutch relay
44 Relay FNR5 transmission relay
45 5A* PETA Pump (PZEV) feedback
46 15A* Injectors
47 15A* PCM class B
48 15A* Coil on plug
49 15A* PCM class C
50 — Not used
51 — Not used
52 Full ISO Relay Blower relay
53 — Not used
54 Full ISO Relay Fuel pump/injectors relay
55 Full ISO Relay Wiper RUN relay
56 — Not used
57 Full ISO Relay PCM relay
58 High Current
Relay
PETA Pump (PZEV)
*Mini fuses **A1 fuses ***A3 fuses
2007 Fusion (fsn)
Owners Guide (post-2002-fmt)
USA (fus)
Roadside Emergencies
197
