Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
9 40A** Ignition switch
10 Not used
11 30A** Powertrain Control Module (PCM)
relay
12 Not used
13 30A** Blower motor (climate control)
14 Not used
15 Not used
16 Not used
17 40A** Anti-lock Brake System (ABS)
module
18 Not used
19 20A** Engine fan
20 Not used
21 10A* PCM keep alive power, Canister
purge valve solenoid
22 Not used
23 30A* Fuel pump motor, Fuel injectors
24 Not used
25 10A* A/C clutch solenoid
26 Not used
27 Not used
28 Not used
29 30A* Wipers/washer
30 Not used
31 15A* Fog lamps
32 Not used
33 30A* Anti-lock Brake System (ABS)
module
34 Not used
35 Not used
36 Not used
2008 Ranger (ran)
Owners Guide (post-2002-fmt)
USA (fus)
