Item Capacity
Ford part name or
equivalent
Ford part number /
Ford specification
Fuel tank–SuperCab
19.5 gallons
(73.8L)
——
1
Add the coolant type originally equipped in your vehicle.
2
Use of synthetic or synthetic blend motor oil is not mandatory. Engine oil need only have the API
Certification mark and meet the requirements of Ford specification WSS-M2C929-A (4.0L) or
WSS-M2C930-A (2.3L and 3.0L).
3
Indicates only approximate dry-fill capacity. Some applications may vary based on cooler size and
if equipped with an in-tank cooler. The amount of transmission fluid and fluid level should be set
by the indication on the dipstick’s normal operating range.
4
Automatic transmissions that require MERCON威 V should only use MERCON威 V fluid or fluid that
is specified dual usage MERCON威/MERCON威 V. Refer to scheduled maintenance to determine
the correct service interval. Use of any fluid other than the recommended fluid may cause
transmission damage.
5
Service refill capacity for the manual transmission is determined by filling the transmission to the
bottom of the filler hole with the vehicle on a level surface.
6
Traction-Lok axles use 4.75-5.0 pints (2.2-2.4L) of rear axle lubricant.
7
Service refill capacities are determined by filling the rear axle 1/4 inch to 9/16 inch (6mm to
14mm) below the bottom of the filler hole.
8
Add 4 oz. (118 ml) of Additive Friction Modifier XL-3 or equivalent meeting Ford specification
EST-M2C118-A for complete refill of Traction-Lok axles.
2008 Ranger (ran)
Owners Guide (post-2002-fmt)
USA (fus)
Maintenance and Specifications
260
