Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
131 5A Power mirrors
132 10A Light switch, Exterior lighting
133 — Not used
134 — Not used
135 — Not used
136 15A Horn
137 7.5A Tire Pressure Monitor System
(TPMS), Radio, Instrument
cluster
138 — Not used
139 — Not used
140 — Not used
141 10A Rear fog lamps
142 15A Brake lamps
143 15A Cigar lighter, Front power point
144 — Not used
145 — Not used
146 20A Windshield wipers, Wiper switch
147 — Not used
148 7.5A Recirculation, Instrument cluster
149 — Not used
150 — Not used
151 15A Radio, Bluetooth/Voice command
module
152 7.5A A/C switch, Park aid module
153 7.5A Interior lamps, Battery saver
154 — Not used
155 — Not used
156 7.5A Right parking lamp/tail lamps
157 7.5A License plate lamps
158 10A Light switch, Turn signal switch
Roadside Emergencies
177
2010 Transit Connect (tst)
Owners Guide (own2002), 1st Printing
