Ford 2010 Transit Connect User Manual

Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
159 — Not used
160 — Not used
161 7.5A Anti-lock Brake System
(ABS)/Traction control, Steering
angle sensor
162 7.5A Airbag module, Passenger airbag
off indicator
163 20A Locks
164 — Not used
165 — Not used
166 25A Front power windows
167 7.5A Rear window defroster/heated
mirror switch
168 — Not used
169 15A Second power point
170 — Not used
171 — Not used
172 — Not used
173 — Not used
174 15A Rear power point
175 7.5A Left park lamps/tail lamps
176 — Not used
177 — Not used
178 25A Rear window defroster
179 7.5A Instrument cluster, Passive
anti-theft system (PATS),
Accelerator pedal sensor, TPMS
180 20A Front and rear window washer
181 — Not used
182 — Not used
Roadside Emergencies
178
2010 Transit Connect (tst)
Owners Guide (own2002), 1st Printing
USA (fus)
