Replacing tail/brake and turn signal bulbs
1. Make sure the headlamp control
is in the off position and open the
trunk.
2. Remove the plastic cover from
inside the luggage compartment.
3. Remove the two nuts from the
lamp assembly
4. Gently pull the lamp assembly
away from the vehicle
5. Remove the turn signal bulb (1)
or the tail/brake bulb (2) by turning
the bulb socket counterclockwise.
Gently pull the bulb straight out of
the socket.
Install the new bulb in reverse
order.
Replacing fog lamp bulbs (if equipped)
1. Make sure the headlamp switch is
in the off position.
2. Reach under the front fender and
remove the aeroshield. Then remove
the harness/bulb assembly from the
fog lamp by turning it
counterclockwise.
3. Disconnect the harness from the
bulb by pulling it straight out.
Install the new bulb in reverse order.
1
2
Lights
132
2012 Focus (foc)
Owners Guide, 1st Printing
USA (fus)
