Ford 2012 FOCUS - Engine Compartment

IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT
(Shown without engine cover, if equipped)
1. Engine coolant reservoir
2. Brake/Clutch fluid reservoir
3. Battery
4. Power distribution box
5. Air filter assembly
6. Engine oil filler cap
7. Engine oil dipstick
8. Windshield washer fluid reservoir
1
2
3
4
6
5
8
7
Maintenance and Specifications
337
2012 Focus (foc)
Owners Guide, 1st Printing
USA (fus)
