Fuse/Relay
Location
Fuse Amp
Rating
Protected circuits
65 10A Trunk/liftgate release
66 20A DD FF unlock supply, double lock
67 7.5A SYNC威, Multifunction Display,
Global positioning system (GPS)
module, Compass
68 — Not used
69 5A Instrument cluster
70 20A Central lock and unlock supply
71 10A Heating control head (manual
A/C), Duel electronic automatic
temperature control
72 7.5A Steering wheel module
73 5A Data link connector
74 15A Low beam headlamp supply
75 15A Fog lamp supply
76 10A Reversing lamp supply
77 20A Windshield washer supply
78 5A Ignition switch, Start button
79 15A Radio, Navigation DVD player,
Touch screen, Hazard light switch,
Door lock switch
80 20A Sunroof supply
81 5A R F receiver
82 20A Windshield washer relay
83 20A Central locking
84 20A DD FF unlock supply, double lock
85 7.5A Passenger air bag deactivation
indicator (PADI ), Front seat
heater switch, Heating module
(manual A/C), Air quality sensor,
Radio, In-car temperature and
humidity sensor
Roadside Emergencies
303
2012 Focus (foc)
Owners Guide, 1st Printing
USA (fus)
