Installing the Engine Air Filter Element
Note: Clean the inside of the air filter assembly before installing a new
air filter.
1. Install the new engine air filter into the engine air cleaner assembly.
2. Install the air cleaner cover (B)
and tighten the 5 bolts.
3. Position the air cleaner assembly
(A) onto the engine and make sure
the assembly is aligned with the
studs.
4. Install and tighten the bolts to
each side of the air cleaner
assembly (A) as shown with arrows.
Maintenance 293
2013 C-Max Full Hybrid (34h)
Owners Guide gf, 2nd Printing
USA (fus)
