• On C-MAX Energi vehicles, slide the
service disconnect handle to the right.
4. Pull the handle toward you and
remove the circuit from the vehicle
to disable the high-voltage battery.
Reverse this procedure to reinstall the service disconnect.
Reactivating the high-voltage battery
Note: If you have manually disconnected your high-voltage shutoff
circuit you will need to reconnect the circuit before it can be reactivated.
The vehicle will detect if the electrical system is safe and reactivate
automatically.
206 High Voltage Battery
2013 C-Max Full Hybrid (34h)
Owners Guide gf, 2nd Printing
USA (fus)
