Ford 2013 C-Max Hybrid User Manual

Setting the Front Wipers in the Service Position
1. Make sure that the outside of the
windshield is free from snow and
ice.
2. Switch on the ignition.
3. Switch off the ignition, and move
the wiper lever to position A within
three seconds. Hold the lever in
position A.
4. Release the lever when the
wipers have moved to the service
position.
Changing the Front Wiper Blades
Set the front wipers in the service position and lift the wiper arms.
1. Press the locking buttons
together.
2. Rotate and remove the wiper
blade.
Note: Make sure that the wiper blade locks into place.
3. Install in the reverse order.
Replace wiper blades at least once per year for optimum performance.
Poor wiper quality can be improved by cleaning the wiper blades and the
windshield.
A
2
1
1
Maintenance 289
2013 C-Max Full Hybrid (34h)
Owners Guide gf, 2nd Printing
USA (fus)
