Identifying Air Filter Element Components

A. Air cleaner assembly

B. Air cleaner cover

C. Air cleaner outlet tube

D. Positive crankcase ventilation (PCV) tube

E. Air cleaner intake tube

Removing the Engine Air Filter Element

1. Loosen the hose clamps for air

cleaner outlet tube (C). Disconnect

the tube from the air cleaner

assembly (A).

A C D

Maintenance 291

2013 C-Max Full Hybrid (34h)

Owners Guide gf, 2nd Printing

USA (fus)
