Ford 2013 Flex - Instrument Cluster; Gauges

GAUGES
Type 1
Cluster shown in standard measure – metric clusters similar.
A. Tachometer
B. Information display. See Information displays for more information.
C. Speedometer
D. Fuel gauge
Fuel gauge
Indicates approximately how much fuel is left in the fuel tank (when the
ignition is on). The fuel gauge may vary slightly when the vehicle is in
motion or on a grade. The fuel icon and arrow indicates which side of
the vehicle the fuel filler door is located.
A
D
CB
Instrument Cluster 107
2013 Flex (471)
Owners Guide gf, 4th Printing, December 2012
USA (fus)
