Fuse or relay
number
Fuse amp
rating
Protected components
29 20A Radio, Global positioning system
module
30 15A Front park lamps, Trailer tow relay
for park lamps, Front side markers
31 5A Trailer tow controller
32 15A Driver window switch and motor,
Power lock switches, Moonroof,
110V AC power point, Interior
rearview mirror
33 10A Not used (spare)
34 10A Blind spot monitor, 2nd row heated
seats, Reverse sensing system,
Rearview camera
35 5A Heads-up display, Climate control
humidity sensor
36 10A Not used (spare)
37 10A Refrigerator
38 10A Front passenger window switch
39 15A High beam headlamps
40 10A Rear park lamps, License plate
lamps
41 7.5A Occupant classification system,
Restraints control module
42 5A Not used (spare)
43 10A Not used (spare)
44 10A Not used (spare)
45 5A Not used (spare)
46 10A Climate control module
47 15A Fog lamps, Fog lamp indicator,
Front turn signals #2
48 30A Circuit
Breaker
Front passenger power window,
Rear power windows
49 Delayed
accessory relay
Body control module
Fuses 297
2013 Flex (471)
Owners Guide gf, 4th Printing, December 2012
USA (fus)
