Ford 2014 FOCUS - Headlamp Assembly; High Beam Headlamp Bulb; Low Beam Headlamp Bulb

Headlamp assembly:
A. High beam headlamp bulb
B. Side marker bulb
C. Low beam headlamp bulb
D. Front parking lamp and turn
signal bulb
High beam headlamp bulb:
1. Remove the headlamp assembly.
2. Remove the service cap.
3. Disconnect the electrical
connector.
4. Remove the bulb from the
headlamp assembly by turning it
counterclockwise, then pull it
straight out.
Install the new bulb in reverse order.
Low beam headlamp bulb:
1. Remove the headlamp assembly.
2. Remove the service cap.
3. Disconnect the electrical
connector.
4. Remove the bulb from the
headlamp assembly by turning it
counterclockwise, then pull it
straight out.
Install the new bulb in reverse order.
Note: Be sure that the spring clip is not damaged or detached from the
headlamp assembly during the replacement procedure.
BA
C
D
248 Maintenance
2014 Focus (foc)
Owners Guide gf, 1st Printing, October 2012
USA (fus)
