CARGO NETS (IF EQUIPPED)

Installing the Net

E171017

1. Push the ends of the upper bar toward

each other and insert them into the

retainers in the roof. Push the bar

forward into the narrow section of the

retainers.

E167370

2. Attach the net to the luggage anchor

points. See Luggage Anchor Points

(page 135).

E167371

136

Tourneo Connect/Transit Connect (CHC) Canada/United States of America, enUSA, Edition date: 07/2013

Load Carrying
