Calculating the Maximum
Loaded Trailer Weight
1. Start with the gross combined
weight rating for your vehicle.
See the following chart.
2. Subtract all of the following
that apply to your vehicle:
• Vehicle curb weight
• Hitch hardware weight
including: draw bar, tow ball,
locks and weight distributing
hardware
• Driver and any passengers
weight
• Payload, cargo or luggage
weight
• Aftermarket equipment
weight.
3. This equals the maximum
loaded trailer weight for this
combination.
Note: The trailer tongue load is an
integral part of the payload of the
vehicle. Reduce the total payload
by the final trailer tongue weight.
Note: Consult an authorized dealer
to determine the maximum trailer
weight allowed for your vehicle if
you are not sure.
Maximum Loaded
Trailer Weight - lb
(kg)
*
Maximum GCWR - lb
(kg)
Powertrain
2,000 lb (907 kg)5,820 lb (2,640 kg)1.6L SWB van
2,000 lb (907 kg)5,919 lb (2,685 kg)1.6L LWB van
2,000 lb (907 kg)5,981 lb (2,713 kg)1.6L SWB wagon
2,000 lb (907 kg)6,180 lb (2,803 kg)1.6L LWB wagon
2,000 lb (907 kg)5,840 lb (2,649 kg)2.5L SWB van
2,000 lb (907 kg)5,959 lb (2,703 kg)2.5L LWB Van
2,000 lb (907 kg)6,021 lb (2,731 kg)2.5L SWB Wagon
2,000 lb (907 kg)6,325 lb (2,869 kg)2.5L LWB Wagon
*
Calculated with SAE J2807 method.
148
Tourneo Connect/Transit Connect (CHC) Canada/United States of America, enUSA, Edition date: 07/2013
Towing
